MULLION-FREE FIRE-RESISTANT WALLS HORYZONT II
DOUBLE-GLAZED ACOUSTIC SYSTEM


volume_off
HORYZONT II Mullion-free walls fire protection
 EI 30 / Sound isolation Rw = 43 dB ( Ra1 = 42 dB )

  • The wall structure is made of a profile with a height of 4 cm
  • Double glazing
  • Fire-resistant laminated glass structurally combined in black or grey colour (visible connection 3-5 mm)
  • Laminated acoustic glass
  • Varnished profiles in any colour. RAL
  • Dimensions max: height = 3 m / width – no restrictions
  • Approval documents: National Technical Assessment ITB / KDWU


volume_off
HORYZONT II Mullion-free walls fire protection
EI 30 / Sound isolation Rw = 45 dB ( Ra1 = 44 dB )

  • The wall structure is made of a profile with a height of 4 cm
  • Double glazing
  • Fire-resistant laminated glass structurally combined in black or grey colour (visible connection 3-5 mm)
  • Laminated acoustic glass
  • Varnished profiles in any colour. RAL
  • Dimensions max: height = 3 m / width – no restrictions
  • Approval documents: National Technical Assessment ITB / KDWU


volume_off
HORYZONT II Mullion-free walls fire protection
EI 60 / Sound isolation Rw ~ 45 dB

  • The wall structure is made of a profile with a height of 4 cm
  • Double glazing
  • Fire-resistant laminated glass structurally combined in black or grey colour (visible connection 3-5 mm)
  • Laminated acoustic glass
  • Varnished profiles in any colour. RAL
  • Dimensions max: height = 3 m / width – no restrictions
  • Approval documents: National Technical Assessment ITB / KDWU

At the customer's request, we can apply:

  • Discoloured glass ( without green shade )
  • System of hidden profiles in technical floor and walls
  • Any graphics on the glass
  • Interior blinds
  • PRIVA-LITE glass for remotely changing the colour of the glass

Why the Horyzont II system?

  • Slimmer structural sections (only 40mm high profile for wall height 3.00m) are not achievable for aluminium in such a high fire-resistant class due to steel profiles' very high lateral stiffness.
  • Thanks to the double-glazing solution, we can use acoustic glass inPRIVA - LITE technology - a transparent glass that changes its opaque form to transparent under an electric current. Regardless of the change in transparency, it is characterised by constant, very high light transmission. Between the two layers of glass, an LC film with liquid crystals is laminated.
  • The mullion-free connection of the glass panel (3-5mm silicone joint between the glass packages) is available in EI 15 / EI 30 /EI60 classes.
  • Powder coating in any RAL colour in own paint shop, which guarantees reproducibility of shades
  • Broad flexibility in constructing complex junctions and shapes.
